Laboratory Constant Temperature Biochemical Incubator Equipped with Auxiliary Temperature Controller
Biochemical incubator is suitable for environmental protection, health and epidemic prevention, drug inspection, agricultural and livestock, aquatic and other scientific research, universities, production departments. It is a special constant temperature equipment for water analysis and BOD determination, culture, preservation, plant cultivation and breeding of bacteria, mould and microorganism.
Features
1.The chamber and working room are designed with circular arc structure.
2.The workroom is made of mirror stainless steel plate, and the shelf can be adjusted freely and assembled freely, which is convenient for cleaning in the workroom.
3. 2 power outlets in the studio with lighting.
4.The workshop is equipped with fans to form forced convection.
5.The surface of the outer box is sprayed with plastic. The whole machine is beautiful, and easy to use and maintain.
6.The door of the incubator is a double door design, the inner door is tempered glass, which can directly observe the conditions of the culture in the working room, and the outer door is a magnetic door seal with good sealing performance.
7. Equipped with leakage protector.
8. Equipped with auxiliary temperature controller to ensure that the machine can still work normally (for heating) in case of loss of control of main temperature controller.
9. It has the function of hot and cold automatic control and adopts the imported compressor.
10. New microcomputer intelligent control system is adopted for temperature control, LCD screen displays temperature with high precision and no overshoot.
11. RS485 communication interface is used to connect computers, display and print temperature and time data with computers, providing strong guarantee for data storage and playback in the test process.
SPECIFICATIONS
|
Model |
LBI-80 |
LBI-150 |
LBI-200 |
LBI-250 |
LBI-300 |
LBI-400 |
|
Chamber Volume (L) |
80L |
150L |
200L |
250L |
300L |
400L |
|
Temperature Range |
0~60 ℃ |
|||||
|
Display Resolution |
0.1 ℃ |
|||||
|
Temperature Stability |
Heating：±0.5℃；Cooling：±1℃ |
|||||
|
Temperature Uniformity |
±1℃ |
|||||
|
Timing Range |
1~9999min |
|||||
|
Power Rating（W） |
180 |
250 |
300 |
350 |
400 |
550 |
|
Refrigerant |
R134a |
|||||
|
Power Supply |
220±10%V, 50Hz |
|||||
|
Continuous Operation |
Long continuous operation |
|||||
|
Chamber Size(W×D×H)cm |
40×37×55 |
45×42×85 |
45×45×100 |
48×49×107 |
52×50×117 |
58×54×127 |
|
Exterior Size(W×D×H)cm |
54×57×107 |
59×62×137 |
59×64×152 |
62×68×159 |
66×69×169 |
72×74×179 |
|
Package Size (W×D×H)cm |
70×73×126 |
75×78×156 |
75×80×171 |
78×84×178 |
82×85×188 |
88×90×198 |
|
Net/Gross Weight（kg） |
50/85 |
90/120 |
95/138 |
103/147 |
115/157 |
135/170 |
|
Shelves(standard/maximum) |
2/8 |
3/13 |
3/15 |
3/16 |
3/18 |
3/20 |
|
Optional Parts |
1.Multi-segment programmable control
2.Built-in printer
3.Φ25mm（50mm）test hole
4.RS485/232 connector 5.Wireless alarm system (SMS alarm system) |
|||||
IPv6 network supported
