Model:PC-24

Model number:PC-30

Model:PC-40

Pressure 0-24 tons

Pressure 0-30 tons

Pressure 0-40 tons

Cylinder diameter 95mm

Cylinder diameter 110mm

Cylinder diameter 130mm

Working space 80*150mm

Working space 92*160mm

Working space 106*185mm

Overall dimensions 245*175*415mm

Overall dimensions 275*195*420mm

Overall dimensions 295*215*500mm

Weight 42kg

Weight 56g

Weight 75kg

Model:PCD-30S

Model number:PCD-40S

Model:PVD-60S

Pressure 0-30 tons

Pressure 0-40 tons

Pressure 0-60 tons

Cylinder diameter 110mm

Cylinder diameter 130mm

Cylinder diameter 150mm

Working space 92*160mm

Working space 115*185mm

Working space 186*220mm

Overall dimensions 275*435*420mm

Overall dimensions 295*455*500mm

Overall dimensions 405*470*565mm

Weight 72kg

Weight 92g

Weight 140kg

Model:PP-30S

Model number:PP-40S

Model:PP-60S

Pressure 0-30 tons

Pressure 0-40 tons

Pressure 0-60 tons

Cylinder diameter 110mm

Cylinder diameter 130mm

Cylinder diameter 150mm

Working space 140*160mm

Working space 175*180mm

Working space 186*220mm

Overall dimensions 230*390*420mm

Overall dimensions 280*460*550mm

Dimensions 300*520*580mm

Weight 95kg

Weight 150g

Weight 180kg

Model:PP-30X

Model number:PP-40X

Model:PP-60X

Pressure 0-30 tons

Pressure 0-40 tons

Pressure 0-60 tons

Cylinder diameter 110mm

Cylinder diameter 130mm

Cylinder diameter 150mm

Built-in boric acid mold

Built-in boric acid mold

Built-in boric acid mold

Overall dimensions 250*390*460mm

Overall dimensions 280*460*550mm

Dimensions 300*520*580mm

Weight 120kg

Weight 150g

Weight 180kg

Model: PMP Boric acid mold

Model number; PMG steel ring mold

Outer diameter 40mm

Outer diameter 40mm

Inner diameter 34mm

Inner diameter 32mm

Consumable boric acid

Consumable steel ring

Overall dimensions Diameter 73mm*130mm

Overall dimensions Diameter 73mm*130mm

Weight 2kg

Weight 2kg
