Small Stainless Steel Vacuum Mixer Machine
Product overview:
The MSK-SFM-7 vacuum mixer can be applied to the mixing process of various solvents and powders, such as lithium-ion batteries, adhesive tapes, solar energy, chemical and other raw material batching processes. It is ideal for laboratory slurry preparation.
Product features:
Equipment design vacuum state, single fan blade stirring paddle, good mixing uniformity.
The machine comes with a vacuum system, effectively eliminating air bubbles generated during mixing.
Gauge vacuum, digital display stirring countdown.
Mixing tank volume standard 150ml stainless steel tank and 550ml aluminium tank, other volume tanks can be ordered.
Configuration of a vibrating plate with adjustable amplitude.
Compact and small equipment with bracket design for easy operation.
Technical parameters:
|
Power supply |
Voltage single-phase 220VAC±10% (110VAC can be customized), frequency 50Hz/60Hz, power 200W |
|
Operating environment |
Recommended ambient temperature 25±3C, humidity 30~90RH, no vibration and electromagnetic interference |
|
Speed of rotation |
320rpm |
|
True empty |
Built-in vacuum pump, vacuum degree -0.08MPa |
|
Stirring time |
0~99min can be set |
|
Mixing jar |
A 150ml effective volume stainless steel can and a 550ml aluminum can are standard, with an optional 30ml stainless steel can |
|
Stir paddle |
Single shaft fan impeller, can also be designed according to customer requirements |
|
Mounting dimensions |
L330mm * H510mm W310mm |
|
Weight |
About 30Kg |
