Main parameter

PN: SX2-1-11TPmini

Max.Temp: 1100C

Working temperature:0-1000C

Chamber size:D100*W100*H100mm

Voltage: 220V single phase

Power:1kw

Heating rate:0~20  Degree/Min，suggest 15C/min

Heating element:Resistance wire

Thermocouple：K type

Temperature accuracy: ±1℃

Furnace Chamber material

Adopt the most advanced light alumina ceramic fiber , with excellent thermal insulation effect, light weight, high temperature resistance, cold and heat resistance.

Furnace chamber design

Furnace adopts the stepped assembly structure, integrating the mechanical law, effectively ensure the furnace in the heating process of uniform force, ensure that the heat is not easy to disperse, prolong the service life of the furnace.

Furnace shell  structure

Electric furnace shell matrial is The furnace shell adopts single-layer carbon steel structure.

Temperature controlling

Adopt international advanced temperature controller, it can set one temperature

Warranty

One year limited warranty with lifetime support, excluding heating element,cooling fans,thermocouple and ceramic tube damaged by user.

Attention: Any damages caused by the use of corrosive and acidic gases, and any damage from wrong operate and use are not under the coverage of One Year Limited Warranty.

Certificates: CE,ISO&UL

Standard Package Accessories:

Electric Furnace

1 set

High temperature gloves

1 pair

Crucible clip

1 pc

User manual

1 book
