300°C Automatic Hot Press with Different Size Heating Die and Optional Water Cooler
Overview
Ryj-600z series automatic hot pressing machine is based on the original split hot pressing machine, developed an intelligent automatic integral double plate hot pressing machine, to meet the large tonnage and large area of sample hot pressing customer demand, widely used in rubber, plastic, film, polymer materials, powder ceramics and other R & D laboratory, is to want to university, The ideal supporting equipment for qualitative analysis of spectral detection by engineering and technical personnel.
The machine adopts 4.3-inch LCD display, program automatic pressure/slow pressure - program pressure holding - automatic pressure filling - timing pressure relief, each heating plate can be independently controlled temperature, and the internal are embedded with cooling water pipe, allowing access to cooling water, in order to quickly cool down.
Parameter
|
Product name |
RYJ-600Z1 |
RYJ-600Z2 |
RYJ-600Z3 |
RYJ-600Z4 |
|
Pressure range |
1-25.0T |
1-30.0T |
1-50.0T |
|
|
Precision of pressure adjust |
0.1t |
0.1t |
0.1t |
|
|
Compression process |
Fully automatic, program pressure/slow pressure - program pressure holding - program pressure replenishing - timing pressure relief |
|||
|
The holding time |
0-999.59(Min/Second) 999 minutes and 59 seconds |
|||
|
Type of thermostat |
PLC program temperature controller |
|||
|
Temperature control range |
||||
|
Heating temperature of die |
RT-300.0℃ |
|||
|
Cooling method of die |
Water cooling (water cooler is optional) |
|||
|
Equipment Insulation Mode |
Imported insulation plate+Stainless steel water-cooled heat shield |
|||
|
Equipment structure |
Integrated structure, automatic program pressure control, temperature control |
|||
|
Die type |
Up and down 2 heating plates, polishing surface |
|||
|
Die size |
180*180mm |
200*200mm |
300*300mm |
400*400mm |
|
Overall size |
280*420*620mm |
280*420*620mm |
400*500*720mm |
500*600*760mm |
|
Power supply |
220/2000W |
220/2000W |
220/3000W |
220/3000W |
|
Equipment weight |
About 150kg |
About160kg |
About300kg |
About400kg |
|
Note |
A hot press, water cooling machine optional! Heating die can be customized according to user demand!!! |
|||
Note: can be customized according to customer demand larger size double plate hot press!!!
