25ML 100ML 500ML 4L Planetary Nylon Ball Mill Jar
Introduction
Nylon ball mill jar is a kind of high quality grinding Jar. Nylon jar does not contain metal impurities, is a variety of metals and high-grade pigment grinding preferred grinding jar, can be widely used in precious metals, electronic ceramics, magnetic materials, color coatings and other industries.
Features
1 Pure white nylon, fine appearance.
2 non-metallic materials, grinding process does not bring in metal impurities.
3 professional design, fine workmanship, beautiful and high quality.
4 High strength, good toughness and good sealing.
Product Parameters
|
Model Specifications |
Outer Diameter(mm) |
Inner Diameter(mm) |
Height (mm) |
|
25ML |
63 |
31 |
65 |
|
50ML |
63 |
43 |
59 |
|
100ML |
68 |
48 |
76 |
|
250ML |
88 |
68 |
98 |
|
500ML |
108 |
88 |
115 |
|
1L |
133 |
109 |
142 |
|
1.5L |
133 |
109 |
178 |
|
2L |
158 |
134 |
172 |
|
2.5L |
158 |
134 |
202 |
|
3L |
158 |
138 |
210 |
|
4L |
178 |
158 |
226 |
|
5L |
218 |
190 |
217 |
|
10L |
246 |
218 |
307 |
|
151 |
273 |
243 |
372 |
|
201 |
320 |
285 |
359 |
|
25L |
320 |
285 |
424 |
Note: 5L-25L ball mill jar clad in stainless steel
Pictures
